Beschrijving
| Mechanical | |
|---|---|
| Dimensions | 122.5 x 107.1 x 28.0 mm (4.82 x 4.22 x 1.10″) |
| Weight | 230 g (8.11 oz) |
| Hardware | |
| Networking interface | (5) 10/100/1,000 MbE RJ45 ports |
| Management interface | Ethernet In-Band |
| PoE Out (Ports 2-5) | PoE+ (Pins 1, 2+; 3, 6-) |
| Ma. power consumption | 5W (Excluding PoE output) |
| Max. PoE wattage per port | 25W |
| Total PoE power budget Powered by PoE Powered by PoE+ Powered by PoE++ Powered by PoE adapter (Enabled in Network Application) |
8W 20W 46W 46W |
| Voltage range PoE PoE+/PoE++ |
44—57V 50—57V |
| ESD/EMP protection | ± 16kV Air, ± 16kV contact |
| Operating temperature 46W PoE output 25W PoE output |
-40 to 55° C (-40 to 131° F) -40 to 65° C (-40 to 149° F) |
| Operating humidity | 5 to 95% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| System | (1) Power: blue/white Flashing white: bootup in progress Flashing blue: firmware upgrading Steady white: factory defaults, awaiting adoption Steady blue: device is adopted |
| Ethernet | PoE Speed/link/activity |
| Power Method (Port 1) | |
| PoE type PoE/PoE+ (Pins 1, 2+; 3, 6-) PoE++ (Pins 1, 2+; 3, 6- and 4, 5+; 7, 😎 50V/60W PoE adapter* |
Recommended PoE source USW-24-PoE (sold separately) USW-Pro-24-PoE (sold separately) PoE Injector, PoE-50-60W-WH or PoE-50-60W (sold separately) * To enable PoE output power, select Power Source PoE Injector in UniFi Application. |
